Clayton Off Road Custom Front Adjustable Track Bar Builder Kit 2.0 Lower | Lower Axle-Side Mount Position | 1-3/4" OD DOM Tube End | Adjustable Heim Joint | High-Steer Application | XJ / ZJ / TJ / LJ Reference Platforms | SKU: COR-4500300

Verified Fitment

This is a fabrication builder kit — not a complete track bar for a specific vehicle. It provides the components to build a custom front adjustable track bar for high-steer front axle conversions on XJ, ZJ, TJ, and LJ platforms (and similar solid front axle applications) where the track bar axle-side mount is at a lower position in the high-steer geometry.

Difference from COR-4500340 (standard high-steer builder kit): COR-4500340 is designed for high-steer setups where the track bar axle-side mount is at the standard high-steer position. COR-4500300 is for high-steer setups where the axle-side mount is at a lower position. The builder must confirm which mount position applies to their specific high-steer configuration before ordering. Text (469) 407-7538 to confirm.

This kit is for custom fabrication only. The builder determines correct track bar length, end geometry, and mounting configuration for their specific high-steer build. This kit provides the hardware components.

Verify application with your build specs: (469) 407-7538

Does NOT Fit

Verify application with your build specs: (469) 407-7538

Component Specifications

What Is and Is NOT Included

Included:

Not Included:

Critical Compatibility

Installation Notes

Skill level: Expert fabricator. Custom track bar fabrication — same process as COR-4500340 but designed for lower axle-side mount position geometry.

Fabrication process:

1. Confirm your high-steer axle mount is at the lower position configuration this kit is designed for.
2. Determine required track bar length for your lower-position high-steer build geometry.
3. Source main track bar tube in 1-3/4" OD DOM at the correct length.
4. Cut main tube to length.
5. Weld included 1-3/4" OD DOM tube end to main tube — full-penetration weld.
6. Thread adjustable heim joint assembly onto the threaded tube end.
7. Set heim joint to correct length for your build geometry. Torque jam nut.
8. Install fabricated track bar in the lower-position high-steer front axle mount.
9. Verify front axle is centered laterally.
10. Complete full front alignment.

Required equipment:

Common Questions

What is the difference between this and COR-4500340 (standard high-steer builder kit)?
Mount position. COR-4500340 is for high-steer setups where the track bar axle-side mount is at the standard high-steer position. COR-4500300 (this kit) is for high-steer setups where the track bar axle-side mount is at a lower position. Both are fabrication builder kits with the same component types (1-3/4" OD DOM tube end, adjustable heim joint, jam nut). The tube end geometry differs to account for the different mount position. Order the kit that matches your high-steer axle mount position. Text (469) 407-7538 if you are unsure which applies to your build.

How do I know if my high-steer setup uses the lower or standard mount position?
The mount position is determined by where the track bar axle-side mount is located on your specific high-steer conversion. Some high-steer conversions position the axle track bar mount higher; others use a lower position. Consult your high-steer kit documentation or text (469) 407-7538 with your axle, high-steer kit, and lift height and OFAS will confirm which builder kit is correct for your configuration.

What main tube do I need?
Source a main track bar tube in 1-3/4" OD DOM steel at the correct length for your lower-position high-steer build geometry. Confirm OD matches the included tube end before ordering your tube.

Does this fit the JK, JL, or JT?
These platforms are not in the reference list for this kit, which covers XJ, ZJ, TJ, and LJ high-steer applications. JK, JL, and JT high-steer custom track bar applications may also use this kit but are not listed as reference platforms. Confirm with OFAS before ordering. Text (469) 407-7538.

The Obsidian Take

This kit is the lower-position variant of the Clayton custom high-steer track bar builder kit. The difference between this and COR-4500340 is one specification: the axle-side mount position. Both are fabrication builder kits for the same reference platforms (XJ, ZJ, TJ, LJ) with the same component types and the same fabrication requirement. The geometry of the tube end differs to match the lower axle mount position.

Ordering the correct kit requires knowing which mount position your high-steer conversion uses. That is the one question to answer before choosing between COR-4500340 (standard position) and COR-4500300 (lower position). If the answer is not immediately clear from the high-steer kit documentation, one call to OFAS resolves it.

Everything else — the fabrication process, the tube OD requirement, the heim joint sizing, the weld-out, the geometry setting — is identical to COR-4500340. The builder's capability determines the quality of the finished bar. The Clayton components provide the hardware.

Manufacturer Data Disclaimer

Product specifications are sourced from Clayton Off Road product documentation and authorized product information. Final track bar geometry, length, and application compatibility are determined by the builder based on their specific high-steer build and lower mount position configuration. Confirm application compatibility with Clayton or OFAS before ordering.

Non-Returnable Notice

Fabrication components are non-returnable once used. Confirm your high-steer build uses the lower axle-side track bar mount position (not standard position — that is COR-4500340) and main tube specifications before ordering. Text (469) 407-7538 with any application questions before your order is placed.
