BEDSLIDE 1000 Classic | 57" x 43" | Black | 2020–2026 Jeep Gladiator JT | 5-Foot Bed | SKU: 10-5743-CLB
Couldn't load pickup availability
Before ordering, verify your vehicle details, current setup, and SKU with OFAS fitment support so your upgrade matches your build.
Shipping & Delivery
Free shipping is available within the lower 48 U.S. states. Large or heavy items may ship by freight, and delivery timing can vary by warehouse, carrier, and product availability.
Fitment, Shipping & Product Support
Verified Fitment
| Year Range | Make | Model | Trim / Platform | Bed Length |
|---|---|---|---|---|
| 2020–2026 | Jeep | Gladiator JT | Sport, Sport S, Willys, Mojave, Overland, Rubicon | 5-foot (~60" interior) |
Does NOT fit:
- Jeep Wrangler (any year, any trim) — the Wrangler is a 2-door or 4-door SUV with no truck bed
- Jeep Renegade, Compass, Grand Cherokee — no truck bed; incompatible
- Any other truck or SUV — the 57x43 platform is sized specifically for the Gladiator's narrower interior width; this is not a universal 5-foot bed size
- Any Gladiator with a spray-in or drop-in bed liner — liner removal required before installation
- Any Gladiator with a soft top or hard top that reduces bed clearance to less than 4.5 inches from the bed floor
Component Specifications
| Specification | Detail |
|---|---|
| SKU | 10-5743-CLB |
| UPC | 850001518482 |
| Platform Dimensions | 57 inches (L) x 43 inches (W) |
| Deck Height | 4.5 inches above truck bed floor |
| Cargo Capacity | 1,000 lb (evenly distributed) |
| Extension | 75% (¾ extension) |
| Frame Construction | Laser-cut formed steel |
| Decking Material | WeatherDeck composite (weather-resistant, lightweight) |
| Width Note | 43" nominal; ¼" manufacturing tolerance applies |
| Finish | Black edition custom finish |
| Grab Bar Width | 32 inches (full-width, accessible from either side) |
| Bearings — Load End | (2) Cam Follower bearings, 3,282 lb static rating each |
| Bearings — Guide Rails | (2) Ball-sealed roller bearings |
| Locking Positions | Multiple |
| Unit Weight | 73.0 lb |
| Country of Origin | Made in USA |
| Warranty | Lifetime (upon registration within 30 days) / 5-year standard |
Why 57x43 and not a standard 5-foot bed size? The Gladiator's bed interior is narrower than a full-size truck's 5.5-foot or 5.7-foot bed and slightly narrower than a Tacoma's 5-foot bed. Bedslide engineered a Gladiator-specific platform to fit the interior correctly. The 57x43 does not fit other trucks, and no other current Bedslide platform is the correct substitute for the Gladiator.
Tier Guide — Jeep Gladiator JT 5-Foot Bed
| SKU | Finish | Capacity | Notes |
|---|---|---|---|
| 10-5743-CLS | Silver | 1,000 lb | Available — see separate listing |
| 10-5743-CLB | Black (this listing) | 1,000 lb | Black edition custom finish |
No Contractor (1,500 lb) or HD (2,000 lb) tier is confirmed for the 57x43 platform at this time.
What Is and Is NOT Included
| Included | NOT Included |
|---|---|
| Bedslide 1000 Classic platform (57" x 43") — black | No-drill factory mount kit — none confirmed for Gladiator |
| Perimeter guardrail system | BedBin Mini Kix — not compatible with Gladiator bed width |
| WeatherDeck composite deck surface | BedBin Side Kix — fitment requires modification in Gladiator bed |
| Full-width 32" grab bar | Tonneau cover or truck cap |
| BedTrax cargo management rail system | Lift Block Kit |
| (4) D-Ring tie-downs | |
| Hard latch system | |
| Standard mounting hardware |
BedBin accessory note: Bedslide's BedBin storage attachments, specifically the Mini Kix and Side Kix bins, do not fit within the Gladiator's narrower bed interior in standard mounting positions. At least one verified owner report (confirmed by Bedslide's engineering department) notes the bed is too narrow for the side bins without relocating mounting plates. If BedBin accessories are a priority, verify fitment with Bedslide directly before purchasing those separately.
Critical Compatibility
The Gladiator bed is narrower than every other mid-size or full-size truck this catalog covers. That narrow interior is the reason this SKU exists — and it's also what creates the installation constraints unique to this platform.
Drilling required: Unlike most Bedslide applications where factory anchor points accept a no-drill kit, the Gladiator does not have a confirmed Bedslide no-drill kit. Standard installation requires drilling new mounting points into the bed floor. If drilling is a firm non-starter, contact us before ordering to verify whether workarounds are available. This is not a no-drill installation out of the box.
Bed liner compatibility: Installing over a spray-in or drop-in liner is not recommended. The Gladiator's already-narrow interior leaves little margin for liner thickness variation without affecting platform alignment. Remove liner before installation.
BedBin accessory incompatibility: The side storage accessories in Bedslide's BedBin line require clearance between the Bedslide platform edges and the truck bed sidewalls. The Gladiator's narrower interior reduces that clearance to the point where Mini Kix bins cannot mount in standard position, and Side Kix bins require plate modification. This is a known, manufacturer-confirmed issue.
Soft top and tonneau cover clearance: The Gladiator is commonly configured with soft tops, hard tops, and folding tonneau covers. Any cover or top that reduces vertical clearance to less than 4.5 inches above the bed floor will conflict with the platform deck height. Measure before ordering either product.
| Scenario | Result |
|---|---|
| 2020–2026 Jeep Gladiator JT — 5-foot bed | Confirmed fit |
| Jeep Wrangler (any year) | Does NOT fit — no truck bed |
| Any other truck or SUV | Does NOT fit — platform is Gladiator-specific |
| Gladiator with spray-in or drop-in liner | Liner removal required |
| Gladiator with soft top / tonneau cover | Confirm 4.5" minimum clearance above bed floor |
| BedBin Mini Kix accessories added | Not compatible without modification |
| BedBin Side Kix accessories added | Requires mounting plate modification |
| No-drill factory mount kit | Not confirmed for Gladiator; drilling required |
Installation Notes
Skill level: Intermediate — drilling new mounting points is required. This is not a plug-and-play bolt-in for the Gladiator. A basic mechanical background and access to a drill are needed.
Estimated time: 1–1.5 hours depending on familiarity with the process.
Tools required:
- Drill with appropriate bit for steel bed floor
- Basic socket set and wrench
- Thread-locking compound (recommended for mounting fasteners)
- Torque wrench (recommended)
No no-drill kit available: Bedslide does not currently offer a factory no-drill mount kit specific to the Gladiator JT. The standard installation uses rivnuts or direct drilling into the bed floor. If this is your first Bedslide installation, professional installation is strongly recommended on the Gladiator application.
Bed liner removal: Remove any spray-in or drop-in bed liner before installation. The Gladiator's narrow interior makes liner thickness a significant variable that can affect alignment.
BedBin accessories: Do not order Bedslide's Mini Kix bins alongside this SKU without verifying current fitment with Bedslide. Side bin mounting in the Gladiator bed requires plate modifications that go beyond standard installation. Bedslide is aware of this issue.
Shipping: This SKU ships LTL freight. Residential delivery is included. OFAS will contact you after order placement to coordinate delivery scheduling. Inspect the unit for shipping damage before signing the delivery receipt — note any damage on the bill of lading before accepting.
Common Questions
Will this fit my Jeep Wrangler?
No. The Wrangler is an SUV — it has no truck bed. The Gladiator JT is the only Jeep truck, and this platform is specifically sized for the Gladiator's 5-foot bed.
Is there a silver version?
Yes — the silver edition is SKU 10-5743-CLS. All dimensions, specifications, and capacity are identical. Only the finish differs.
Does this require drilling?
Yes, for the Gladiator specifically. Unlike most Bedslide applications, no factory no-drill mount kit is confirmed for the Gladiator JT. Standard installation requires drilling new mounting points into the bed floor. If you are not comfortable drilling into your bed, professional installation is the correct path.
Does the slide pull all the way past the tailgate?
No. The Classic operates at 75% (¾) extension — it extends far enough to reach everything from beside the tailgate without climbing in, but does not travel completely past the tailgate plane.
Can I use BedBin accessories with this?
Not all of them without modification. Bedslide's Mini Kix bins are incompatible with the Gladiator's narrow bed in standard mounting position. Side Kix bins require mounting plate modifications. Do not order BedBin accessories alongside this SKU without verifying current fitment status with Bedslide.
Will this work under my tonneau cover or soft top?
It depends on clearance. The platform deck sits 4.5 inches above the bed floor. Confirm your cover or top provides at least 4.5 inches of vertical clearance before ordering either product.
The Obsidian Take
The 10-5743-CLB is one of the most purpose-specific SKUs in the Bedslide Classic lineup — it exists entirely because the Gladiator's bed is narrower than every comparable mid-size and full-size truck in the segment. No universal platform fits it correctly. If you have a Gladiator and you want a cargo slide, this is your only confirmed Bedslide option at the Classic tier.
The black finish makes practical sense on the Gladiator more than on most trucks. Gladiator buyers are disproportionately running the truck in outdoor and off-road contexts where trail dust, dirt, and mud contact the bed routinely. Black hides surface accumulation better than silver and aligns aesthetically with the matte and satin exterior finishes common across Gladiator trims — particularly the Rubicon and Mojave. If finish color is genuinely neutral to you, black is the more pragmatic choice here.
The drilling requirement is the one honest inconvenience this platform carries. Every other Classic-tier SKU in this catalog has a no-drill kit option for at least one of its vehicle applications. The Gladiator does not. That means your installation is slightly more permanent and slightly more involved than comparable trucks. A professional shop with Bedslide experience handles this correctly in under two hours — factor that in as an optional line item if you'd rather not drill yourself.
This SKU is for: 2020–2026 Gladiator JT owners across all trims who want a 1,000 lb cargo slide platform in black, are prepared for a drill-in installation, and don't need BedBin Mini Kix accessories.
This SKU is NOT for: Anyone who owns a Wrangler instead of a Gladiator (no truck bed), anyone who needs a no-drill installation and isn't willing to hire it out, anyone expecting to add Mini BedBin accessories in standard configuration, or anyone with a bed liner who isn't planning to remove it first.
