Bedslide

Bedslide 1000 Classic Cargo Slide | 63" x 47" | 1,000 lb Capacity | 5.5‑Foot Super Short Bed | Toyota Tundra / Chevy Suburban / Chevy Tahoe | Black Edition | SKU: 10‑6347‑CLB

SKU: 10-6347-CLB
(0)
In stock
Available to order — same-day processing before 12 PM CST
$1,880.00
Confirm Fitment With Confidence

Before ordering, verify your vehicle details, current setup, and SKU with OFAS fitment support so your upgrade matches your build.

Shipping & Delivery

Free shipping is available within the lower 48 U.S. states. Large or heavy items may ship by freight, and delivery timing can vary by warehouse, carrier, and product availability.

Fitment, Shipping & Product Support

Chat Email 469-407-7538

Verified Fitment

This slide is engineered for 5.5‑foot super short beds where the application data assigns a 63" x 47" Classic platform:

  • Toyota Tundra with 5.5‑foot super short bed.

  • Chevrolet Suburban with 5.5‑foot super short bed.

  • Chevrolet Tahoe with 5.5‑foot super short bed.

Fitment is both bed‑length and platform‑size dependent. If your Tundra, Suburban, or Tahoe application data calls for the 63" x 47" Classic 1,000 lb deck and your bed length is 5.5 ft, this SKU is in the correct family. If your guide calls for other platform sizes (for example, 65" x 48" or 68" x 48"), you must use those instead.

Verify fitment by text: (469) 407‑7538.

Does NOT Fit

Exclusion Reason
Trucks with 6.5' or longer beds 63" x 47" deck is engineered for 5.5‑foot super short beds; longer beds require larger platforms.
Trucks that take other deck sizes Vehicles mapped to 65" x 48", 68" x 48", 78" x 48", or other platform sizes must use those decks.
Other brands (Ford, Ram, Nissan, etc.) Application and brackets are specific to Tundra, Suburban, and Tahoe; other trucks use different platforms.
Beds with equipment blocking rail area Toolboxes, tall liners, fifth‑wheel hardware or tailgate steps can block rail placement or deck travel.

Verify fitment by text: (469) 407‑7538.

Component Specifications

Component Specification
Platform dimensions 63 inches length x 47 inches width—Classic‑series deck sized for 5.5‑foot super short Tundra, Suburban, and Tahoe beds.
Rated capacity 1,000 lb capacity, evenly distributed static load—Classic‑tier half‑ton drawer rating.
Extension Full extension to the tailgate—deck travels out to the tailgate plane for direct access.
Deck height above bed Approximately 4.5 inches from bed floor to deck surface (Classic profile).
Deck surface Composite or WeatherDeck‑style decking designed for all‑weather durability and cargo stability.
Bearing configuration Cam‑follower bearings at the load‑bearing end paired with sealed roller bearings at the guide end.
Tie‑down provision Multiple tie‑down locations with integrated anchors or D‑rings to secure cargo on the deck.
Guardrail Guardrail around the deck perimeter to help keep cargo on the platform during travel.
Locking positions Multiple locking positions along the travel range for safety and convenience under load.
Grab bar Front grab bar at the deck face for controlling the slide from the tailgate area.
Latch system Hard latch mechanism integrated with the rail and bearing system for secure lock‑in and lock‑out positions.
Finish Black Edition finish on frame and visible components for SKU 10‑6347‑CLB.
Unit weight Classic‑profile system weight appropriate for a 63" x 47" deck; use manufacturer spec for exact value if needed.
Product series Bedslide 1000 Classic series—Black Edition variant of the 1,000 lb Classic slide.

What Is and Is NOT Included

Included

Component Notes
Bedslide 10‑6347‑CLB cargo slide Classic 1000 Black Edition platform and rail assembly in 63" x 47" size for 5.5‑foot super short beds.
Deck surface Composite or WeatherDeck‑style decking rated for all‑weather use.
Guardrail system Guardrail around the deck perimeter to help keep cargo secure.
Tie‑down anchors Integrated tie‑down points and anchors for strapping cargo down.
Bearing and latch hardware Cam‑follower bearings, sealed roller guides, and latch hardware included.
Standard installation hardware Bolts, fasteners, and mounting hardware supplied as part of the Classic 1000 kit.

Not Included

Item Notes
Contractor / Heavy Duty tiers Contractor 1,500 lb platforms (15‑6347‑CGB, 15‑6347‑CG) and any Heavy Duty platforms are separate SKUs.
Model‑specific bracket kits Brackets required for composite or special bed structures are not included and must be sourced separately where specified.
Bedliner or bed protection Spray‑in or drop‑in bedliners, mats, and other bed protection products are not included.
BedBin accessory system BedBin dividers, Side Kix, Mini Kix, Upper Tray, and related accessories are sold separately.
Tailgate step clearance kits Spacer or clearance kits for integrated tailgate steps are not included and should be ordered separately if needed.
Professional installation labor Dealer or shop labor is not included; installation cost is separate from the product.

Critical Compatibility

System / Condition Interaction and requirement
5.5‑foot super short bed length 63" x 47" platform is engineered for 5.5‑foot super short beds; other bed lengths use different platform families.
Platform family differences Vehicles mapped to other platform sizes must use those decks; installing 10‑6347‑CLB where a different size is specified leads to misfit.
Composite or aluminum beds Composite or aluminum bed constructions may require model‑specific brackets or no‑drill kits to avoid drilling and protect the bed.
Bedliners (spray‑in / drop‑in) Bedliners can prevent hardware from seating correctly and misalign rails; liner removal or trimming may be required in mounting zones.
Existing bed accessories Toolboxes, rack systems, fifth‑wheel hardware, and tailgate steps can interfere with rail placement and slide travel; verify clearance before ordering.
Load usage patterns 1,000 lb rating assumes evenly distributed static load; concentrated point loads and impacts should be avoided.

Installation Notes

Complexity: Intermediate. The platform and rails must be centered and bolted to the bed structure so the slide travels smoothly and locks reliably at the 1,000 lb rating; a second person is recommended for lifting and positioning the assembly.

Install method: On steel 5.5‑foot super short beds, installation uses the supplied hardware and bed floor following layout and torque guidance. On composite or special bed constructions, model‑specific brackets or no‑drill kits may be required to avoid drilling into the bed and to protect the material.

Bedliners and accessories: Spray‑in and drop‑in liners, toolboxes, racks, and tailgate steps may interfere with mounting or travel. Plan to remove or trim liner material where the rails mount and verify clearance to tailgate, bed walls, and any covers or caps before installation.

Post‑install: Cycle the slide under partial load, confirm all locking positions engage, verify clearance at tailgate and bed walls, and only then load to full capacity.

Common Questions

Will this slide fit my Tundra, Suburban, or Tahoe 5.5‑foot super short bed?
If your truck has a 5.5‑foot super short bed and your application data assigns the 63" x 47" Classic platform to that bed, this Black Edition Classic 1000 slide is in the correct fitment family; applications mapped to other deck sizes require those platforms instead.

What happens if I install this on a longer bed?
A 63" x 47" platform will not cover longer beds correctly and may not mount as designed; incorrect bed length and platform size combinations lead to misfits that are non‑returnable once used.

Can I install this on a composite or special bed without brackets?
Composite or special bed constructions require model‑specific brackets or no‑drill kits to protect the bed and provide proper mounting; installing without them can damage the bed or compromise hardware seating.

Can I install this over a bedliner?
Bedliners add material between hardware and bed floor; installing directly over a liner may prevent bolts and brackets from seating correctly and misalign the rails. Removing or trimming liner material where the rails mount is the safest installation approach.

Does this slide work under a tonneau cover or truck cap?
Classic 1000 slides are designed to let you access gear from the tailgate under a cover or cap; confirm vertical clearance for the deck height and slide travel range against your specific cover or cap profile.

Verify fitment or ask additional questions by text: (469) 407‑7538.

The Obsidian Take

This slide is for the Tundra, Suburban, or Tahoe owner whose truck has a 5.5‑foot super short bed mapped to the 63" x 47" Classic platform and who needs 1,000 lb cargo handling in a black finish. It turns the short bed into an organized half‑ton drawer that you can reach from the tailgate, even under a cover or cap.

It is not for longer‑bed trucks, for applications that require other platform sizes, or for buyers who regularly need more than 1,000 lb capacity—those demand different deck dimensions and, in some cases, different tiers. It is also not for beds installed without the correct brackets on composite or special constructions, or for trucks where bedliners and equipment block proper mounting.

If your Tundra, Suburban, or Tahoe bed matches the 63" x 47" Classic fitment and your loads stay within the 1,000 lb envelope, this Black Edition slide is a right‑sized tool that makes everyday access safer and more efficient without over‑building the system for your vehicle.

Manufacturer Data Disclaimer

Product images and technical data are manufacturer‑provided for reference only; actual product appearance, components, packaging, finishes, and fitment details may vary by application, part number, or manufacturer updates.

Confirm current specifications and fitment details with OFAS or the manufacturer before purchase or installation, especially if your vehicle has bedliners, tailgate steps, or non‑standard bed accessories.

Prop 65 Warning

WARNING: This product can expose you to chemicals, including those known to the State of California to cause cancer and reproductive harm. For more information, visit www.P65Warnings.ca.gov.

Non‑Returnable Notice

This item is non‑returnable once installed and used, because installation and load application change the condition of the slide and hardware.

Text (469) 407‑7538 with your year, make, model, bed length, bedliner type, and bed material before purchasing if you have fitment or installation questions so the correct platform and tier can be shipped the first time.
