Baja Designs LP4 Pro LED Light Pods | Clear Lens | Driving/Combo Pattern | Pair | SKU: 297803
Couldn't load pickup availability
Before ordering, verify your vehicle details, current setup, and SKU with OFAS fitment support so your upgrade matches your build.
Shipping & Delivery
Free shipping is available within the lower 48 U.S. states. Large or heavy items may ship by freight, and delivery timing can vary by warehouse, carrier, and product availability.
Fitment, Shipping & Product Support
The LP4 Pro Clear is a dual-row rectangular LED light pod built for maximum output in clean-air conditions — trail, overlanding, and work environments where dust and fog are not a factor. The clear polycarbonate lens delivers full-spectrum daylight white output at 5000K with no wavelength filtering, putting the full capability of the dual-row array to work in conditions where scatter-back is not a concern.
The driving/combo pattern gives you long-range forward projection with lateral spread — more reach than a wide or cornering pattern, balanced for both distance and peripheral coverage. For environments where dust, fog, sand, or rain regularly reduce visibility, the amber lens variant (297813) is the correct selection — amber filters the blue wavelengths responsible for scatter-back in particulate and precipitation.
This listing is a pair — two LP4 Pro clear pods. Single unit amber: 297013. Amber lens pair: 297813.
IP69K rated. Die-cast aluminum housing. Wiring harness required — sold separately.
Component Specifications
| Component | Specification |
|---|---|
| SKU | 297803 |
| Brand | Baja Designs |
| Model | LP4 Pro |
| Form Factor | Rectangular pod — dual-row LED array |
| Lens Material | Polycarbonate — clear |
| Beam Pattern | Driving/Combo |
| Housing Material | Die-cast aluminum |
| IP Rating | IP69K — waterproof, dust-tight, pressure-wash rated |
| Color Temperature | 5000K — daylight white |
| Quantity | Pair (2 pods) |
| Weight | 10 lbs (pair) |
| Wiring Harness | Sold separately — required |
| Mount Footprint | Rectangular — LP4-compatible mounts only |
| Application | Universal |
What Is and Is NOT Included
| Included | Not Included |
|---|---|
| LP4 Pro clear lens pods — qty 2 | Wiring harness — required, sold separately |
| Mounting brackets or hardware | |
| Vehicle-specific adapters |
Critical Compatibility
The LP4 Pro is a rectangular pod. It does not share a mounting footprint with any round Baja Designs pod. S2 Sport, S2 Pro, Squadron Sport, Squadron Pro, XL Sport, and XL80 are all round pods — their mounts will not accept the LP4 body. There is no adapter. If your existing mount was built for a round pod, a new LP4-compatible rectangular mount is a required separate purchase.
The LP6 is a larger rectangular pod used in vehicle-specific bumper and DOT headlight replacement kits — it is not interchangeable with the LP4 Pro in universal auxiliary light applications.
| Configuration | Compatibility |
|---|---|
| Round pod mounts — S2, S2 Pro, Squadron Sport, Squadron Pro, XL Sport, XL80 | ❌ Not compatible — rectangular body will not seat in round pod mount |
| LP6 mounts or LP6 vehicle-specific brackets | ❌ Not compatible — LP6 is a larger pod with a different footprint |
| Any mount not structurally rated for 10 lbs per pair | ❌ Not compatible — verify mount structural rating before ordering |
| Factory wiring without relay harness | ❌ Not compatible — LP4 Pro dual-row draw exceeds factory switch circuit ratings |
| Dust, fog, sand, or rain as primary operating environment | ❌ Use-case mismatch — clear lens produces scatter-back in particulate; see amber 297813 |
| On-road use in jurisdictions restricting auxiliary lighting | ❌ Verify compliance with your state DMV or DOT before road use |
Mount question before you order? Text (469) 407-7538.
Installation Notes
Mount footprint: LP4 Pro requires an LP4-compatible rectangular mount. Confirm your mount is designed for the LP4 rectangular body before ordering. If you are upgrading from any round Baja Designs pod, budget for a new mount.
Structural rating: The pair weighs 10 lbs. Off-road vibration at speed multiplies static load significantly. Verify your mount is structurally rated for the LP4 Pro at your intended operating conditions before installing.
Relay harness — required before any wiring: The LP4 Pro dual-row LED array draws more current than factory light switch circuits are rated to handle. A relay harness rated for the LP4 Pro current draw must be purchased and installed before the pods connect to any power source. Skipping the relay harness risks burning the factory switch circuit and damaging vehicle wiring. Not included.
Aim before final torque: Set beam angle at your intended aim point before fully torquing mount hardware.
Connector sealing: Fully seat and weatherproof all wiring connectors after installation. IP69K rating applies to the pod housing — connector integrity is installer responsibility.
Road legality: Auxiliary lighting regulations vary by state. Confirm compliance with your state DMV or DOT before on-road use.
Text (469) 407-7538 to confirm the correct harness and mount for your application before ordering.
The Obsidian Take
If your environment is clean air — dry trail, open overland, work lighting — and maximum raw output is the priority, the LP4 Pro Clear is the correct pod. Nothing is filtered, nothing is sacrificed, and the full dual-row array works exactly as built. IP69K housing and die-cast aluminum construction mean it handles the elements on the outside regardless of what lens you're running — the lens selection is purely about what your operating environment throws at the beam.
If dust, fog, sand, or rain are regular factors in your environment, this is not the right lens. Run 297813 and filter the scatter before it works against you.
The LP4 Pro Clear is the right call when your air is as clean as your output needs to be.
Common Questions
Will my Squadron Pro mount work with the LP4 Pro?
No. The Squadron Pro is a round pod. The LP4 Pro is rectangular — different mounting footprint, no adapter available. A new LP4-compatible rectangular mount is required.
Is the wiring harness included?
No. A relay harness is required for installation and sold separately. Confirm the harness is rated for the LP4 Pro dual-row current draw before purchasing.
What is the difference between the LP4 and the LP6?
The LP4 Pro is a compact rectangular pod for universal auxiliary light applications. The LP6 is a larger rectangular pod used in vehicle-specific bumper kits and DOT headlight replacement applications — it is not a universal auxiliary pod and the two are not interchangeable.
What is the difference between clear and amber LP4 Pro?
Clear (297803) delivers maximum output in clean-air conditions with no wavelength filtering. Amber (297813) filters blue wavelengths that scatter in dust, fog, sand, and rain — the correct choice when your environment regularly reduces visibility. Amber reduces output in clear conditions.
Is this a pair or a single pod?
This listing is a pair — two LP4 Pro clear pods.
Can I use this on the road?
Auxiliary lighting legality varies by state. Confirm compliance with your state DMV or DOT before on-road use.
Verified Fitment
Universal mount application. Compatible with any vehicle, truck, UTV, or equipment with a mounting solution designed for the LP4 Pro rectangular pod footprint. Mount selection and wiring harness compatibility are buyer's responsibility.
