Baja Designs LP4 Pro LED Light Pods | Amber Lens | Driving/Combo Pattern | Pair | SKU: 297813
Couldn't load pickup availability
Before ordering, verify your vehicle details, current setup, and SKU with OFAS fitment support so your upgrade matches your build.
Shipping & Delivery
Free shipping is available within the lower 48 U.S. states. Large or heavy items may ship by freight, and delivery timing can vary by warehouse, carrier, and product availability.
Fitment, Shipping & Product Support
The LP4 Pro Amber is a dual-row rectangular LED light pod built for dust, fog, sand, and rain — environments where white light scatters back off airborne particulate and cuts effective visibility rather than extending it. The amber polycarbonate lens removes the blue wavelengths responsible for that scatter, delivering sharper contrast, better depth perception, and usable forward throw at speed in conditions that defeat a clear lens.
The driving/combo pattern gives you long-range forward projection with lateral spread — more reach than a wide or cornering pattern, purpose-built for desert and dusty trail environments where both distance and peripheral coverage matter simultaneously.
This listing is a pair — two LP4 Pro amber pods. Single unit: 297013. Clear lens pair for clean-air maximum output: 297803.
IP69K rated. Die-cast aluminum housing. Wiring harness required — sold separately.
Component Specifications
| Component | Specification |
|---|---|
| SKU | 297813 |
| Brand | Baja Designs |
| Model | LP4 Pro |
| Form Factor | Rectangular pod — dual-row LED array |
| Lens Material | Polycarbonate — amber |
| Beam Pattern | Driving/Combo |
| Housing Material | Die-cast aluminum |
| IP Rating | IP69K — waterproof, dust-tight, pressure-wash rated |
| Color Temperature | Amber |
| Quantity | Pair (2 pods) |
| Weight | 10 lbs (pair) |
| Wiring Harness | Sold separately — required |
| Mount Footprint | Rectangular — LP4-compatible mounts only |
| Application | Universal |
What Is and Is NOT Included
| Included | Not Included |
|---|---|
| LP4 Pro amber lens pods — qty 2 | Wiring harness — required, sold separately |
| Mounting brackets or hardware | |
| Vehicle-specific adapters |
Critical Compatibility
The LP4 Pro is a rectangular pod. It does not share a mounting footprint with any round Baja Designs pod. S2 Sport, S2 Pro, Squadron Sport, Squadron Pro, XL Sport, and XL80 are all round pods — their mounts will not accept the LP4 body. There is no adapter. If your existing mount was built for a round pod, a new LP4-compatible rectangular mount is a required separate purchase.
| Configuration | Compatibility |
|---|---|
| Round pod mounts — S2, S2 Pro, Squadron Sport, Squadron Pro, XL Sport, XL80 | ❌ Not compatible — rectangular body will not seat in round pod mount |
| Any mount not structurally rated for 10 lbs per pair | ❌ Not compatible — verify mount structural rating before ordering |
| Factory wiring without relay harness | ❌ Not compatible — LP4 Pro dual-row draw exceeds factory switch circuit ratings |
| Clear-condition, clean-air primary use | ❌ Use-case mismatch — amber filters output useful in clear air; see 297803 |
| On-road use in amber-restricted jurisdictions | ❌ Verify compliance with your state DMV or DOT before road use |
Mount question before you order? Text (469) 407-7538.
Installation Notes
Mount footprint: LP4 Pro requires an LP4-compatible rectangular mount. Confirm your mount is designed for the LP4 rectangular body before ordering. If you are upgrading from any round Baja Designs pod, budget for a new mount.
Structural rating: The pair weighs 10 lbs. Off-road vibration at speed multiplies static load significantly. Verify your mount is structurally rated for the LP4 Pro at your intended operating conditions before installing.
Relay harness — required before any wiring: The LP4 Pro dual-row LED array draws more current than factory light switch circuits are rated to handle. A relay harness rated for the LP4 Pro current draw must be purchased and installed before the pods connect to any power source. Skipping the relay harness risks burning the factory switch circuit and damaging vehicle wiring. Not included.
Aim before final torque: Set beam angle at your intended aim point before fully torquing mount hardware.
Connector sealing: Fully seat and weatherproof all wiring connectors after installation. IP69K rating applies to the pod housing — connector integrity is installer responsibility.
Road legality: Amber auxiliary lighting regulations vary by state. Off-highway use is unrestricted. For on-road use, confirm compliance with your state DMV or DOT before mounting.
Text (469) 407-7538 to confirm the correct harness and mount for your application before ordering.
The Obsidian Take
If your rig runs desert, dusty trail, sand, or fog with any regularity, amber is the correct lens selection and the LP4 Pro is the correct pod for the job. IP69K housing, die-cast aluminum construction, dual-row output in a driving/combo pattern — purpose-built for exactly the conditions where clear light becomes a liability. The rectangular form factor and 10 lb pair weight mean your mount selection matters as much as the pod itself — get that right and this is a lighting system that will outlast the vehicle it's on.
If your environment is consistently clear and dry and your priority is maximum raw output, this is not the right lens for your build. Run 297803 and put all of your output to work in the conditions you actually drive in.
The LP4 Pro Amber earns its place on rigs that earn their dust.
Common Questions
Will my Squadron Pro mount work with the LP4 Pro?
No. The Squadron Pro is a round pod. The LP4 Pro is rectangular — different mounting footprint, no adapter available. A new LP4-compatible rectangular mount is required.
Is the wiring harness included?
No. A relay harness is required for installation and sold separately. Confirm the harness is rated for the LP4 Pro dual-row current draw before purchasing.
What is the difference between the amber and clear LP4 Pro?
Amber (297813) filters blue wavelengths that scatter in dust, fog, sand, and rain — better contrast and depth perception in low-visibility conditions, reduced output in clear air. Clear (297803) delivers maximum output in clean-air conditions and is the correct choice when dust and fog are not factors.
Is this a pair or a single pod?
This listing is a pair — two LP4 Pro amber pods. Single unit: 297013.
Can I use this on the road?
Amber auxiliary lighting is legal for off-highway use. On-road legality varies by state — confirm with your state DMV or DOT before road use.
Verified Fitment
Universal mount application. Compatible with any vehicle, truck, UTV, or equipment with a mounting solution designed for the LP4 Pro rectangular pod footprint. Mount selection and wiring harness compatibility are buyer's responsibility.
Manufacturer Data Disclaimer: Specifications sourced from Baja Designs product documentation and authorized distributor data. Obsidian Forged Auto Supply is an authorized Baja Designs dealer. Manufacturer specifications are subject to change without notice.
⚠️ California Proposition 65 Warning: This product may expose you to chemicals known to the State of California to cause cancer or reproductive harm. For more information visit P65Warnings.ca.gov.
⚠️ Non-Returnable Notice: Electrical components that have been wired or powered are non-returnable. Confirm compatibility before installation.
