Axiom Supply Heavy Duty Chromoly Lug Nut | M12x1.5 | Acorn/Conical Seat | UTV Wheel Hardware | SKU AXLG1
Couldn't load pickup availability
Before ordering, verify your vehicle details, current setup, and SKU with OFAS fitment support so your upgrade matches your build.
Shipping & Delivery
Free shipping is available within the lower 48 U.S. states. Large or heavy items may ship by freight, and delivery timing can vary by warehouse, carrier, and product availability.
Fitment, Shipping & Product Support
The Axiom Heavy Duty Chromoly Lug Nut (SKU AXLG1) is a high-strength replacement lug nut for UTV wheels using M12x1.5 thread pitch. Crafted from 4140 aircraft-grade chromoly steel and heat-treated for maximum impact resistance, delivering superior clamping force and durability under high-frequency vibration and repeated impact loads. Precision CNC-machined threads for consistent engagement. Heavy-duty gold zinc finish for corrosion resistance in mud and salt. Acorn/conical seat design. Purpose-built for UTV, off-road, and performance applications. Sold individually — order the quantity needed for your application.
Component Specifications
| Spec | Detail |
|---|---|
| SKU / Part Number | AXLG1 |
| Brand | Axiom Supply |
| Thread | M12x1.5 |
| Material | 4140 aircraft-grade chromoly steel, heat-treated |
| Seat Type | Acorn / Conical |
| Finish | Gold zinc |
| Quantity | Single lug nut — order as needed |
| Application | UTV wheel hardware — off-road, high-vibration environments |
| Price | Starting at $6.99 |
| Sold As | Each |
What Is and Is NOT Included
| Item | Included |
|---|---|
| 1x M12x1.5 chromoly lug nut, acorn/conical seat | ✓ |
| Installation socket | ✗ NOT included — verify your socket size (commonly 3/4" or 19mm for this style, confirm for your specific application) |
| Lug nuts of a different seat type (ball, flat) | ✗ NOT included — a different part number is required for non-conical wheel seats |
Verified Fitment
| Application | Status |
|---|---|
| UTV wheels with M12x1.5 thread and acorn/conical seat | ✓ |
| UTV wheels with M12x1.25 thread | ✗ Different pitch — confirm before ordering |
| UTV wheels with ball/radius or flat seat type | ✗ Different seat type — this part is conical seat only |
| M10 or M14 thread applications | ✗ Not compatible |
Critical Compatibility
| Configuration | Notes |
|---|---|
| M12x1.25 thread pitch | Not compatible — cross-threading will damage the hub stud; confirm pitch before ordering |
| Ball/radius or flat wheel seats | This SKU is acorn/conical seat only — a mismatched seat type will not clamp correctly and can cause wheel loosening or stud damage |
| Aluminum wheel seats | Confirm hardness compatibility — the harder chromoly nut can gall softer aluminum seat surfaces if not matched correctly |
| Limited wheel bore clearance | Acorn/conical style lug nuts generally require adequate bore clearance around the stud to seat properly — verify clearance with your specific wheel |
Common Questions
Will this fit my wheel if it uses a ball-seat or flat-seat lug nut style?
No. This specific part is acorn/conical seat only. A mismatched seat type will not clamp correctly, even if the thread pitch matches. Confirm your wheel's seat type before ordering.
What socket size do I need?
Verify against your specific application, but this style of M12x1.5 chromoly lug nut commonly uses a 3/4" or 19mm socket.
How many do I need?
Sold individually. Order one per stud — typically 4 or 5 per wheel depending on your UTV's bolt pattern, times the number of wheels you're servicing.
What's the torque spec?
Torque to your UTV manufacturer's specification for your specific hub and wheel combination. Typical M12x1.5 UTV lug nut torque ranges from 35–45 ft-lbs, but verify in your service manual — do not use an impact wrench without a torque stick.
The Obsidian Take
The AXLG1 is for the UTV owner replacing worn, stripped, or damaged lug nuts who wants real strength upgrade over standard carbon steel — 4140 chromoly, heat-treated, gold zinc finish for mud and salt resistance. Acorn/conical seat fits a wide range of aftermarket wheels.
The two checks that matter before ordering: confirm your thread pitch is M12x1.5, not the common M12x1.25 alternative, and confirm your wheel uses a conical seat — this part won't clamp correctly on a ball-seat or flat-seat wheel design.
Non-Returnable Notice: Installed fasteners are non-returnable. Confirm thread pitch and seat type match your application before ordering.
Manufacturer Data Disclaimer: Specifications sourced from Axiom Supply and authorized distributor documentation. Obsidian Forged Auto Supply is an authorized Axiom Supply dealer. Manufacturer specifications are subject to change without notice.
