Apex Chassis ProLock Drag Link | 2" Black Anodized 7075-T6 Aluminum | 2014-2026 Ram 2500 / 2013-2026 Ram 3500 4WD | SKU KIT387-BLK
Couldn't load pickup availability
Before ordering, verify your vehicle details, current setup, and SKU with OFAS fitment support so your upgrade matches your build.
Shipping & Delivery
Free shipping is available within the lower 48 U.S. states. Large or heavy items may ship by freight, and delivery timing can vary by warehouse, carrier, and product availability.
Fitment, Shipping & Product Support
The Apex Chassis ProLock Drag Link (KIT387-BLK) is a direct-replacement extreme-duty drag link for the 2014–2026 Ram 2500 and 2013–2026 Ram 3500 4WD SRW. 2" black anodized 7075-T6 aircraft-grade aluminum adjusting rod, SAE 1045 CNC-machined forged steel housings, SAE 4140 hot-forged induction heat-treated chromoly ball studs, ProLock™ machined keyway washers, jam nuts with 3 wrench-flat set screws, internal Flopper Stoppers (27° left/right, 2° front/back), reversible stainless steel taper sleeve for flip applications. Gas and 6.7L Cummins diesel. 2–6" lift range. Full front-end alignment required post-install.
Mechanically identical to KIT387-POL — same 2" 7075-T6 rod, same ProLock system, same 21 lbs. The only difference is finish. Drag link only — tie rod sold separately as KIT386-BLK. Complete master kit KIT385-BLK bundles both for one installation and one alignment fee. 2013 Ram 2500 does NOT fit. Ram 3500 DRW requires a different SKU.
Component Specifications
| Spec | Detail |
|---|---|
| SKU / Part Number | KIT387-BLK |
| Brand | Apex Chassis |
| Platform | 2014–2026 Ram 2500 4WD / 2013–2026 Ram 3500 4WD SRW |
| Component | Drag link only — tie rod sold separately (KIT386-BLK) |
| Complete Kit | KIT385-BLK — drag link + tie rod bundled |
| Polished Version | KIT387-POL — mechanically identical, raw mirror polished finish |
| Adjusting Rod | 2" black anodized 7075-T6 aircraft-grade aluminum |
| Housings | SAE 1045 solid steel forged — CNC machined |
| Ball Studs | SAE 4140 hot-forged chromoly — induction heat treated, rolled step threads |
| Adjustment System | ProLock™ machined keyway washers + jam nuts with 3 wrench-flat set screws |
| Joint Type | High-misalignment ends with internal Flopper Stoppers |
| Flopper Stoppers | 27° left/right stud travel · 2° front/back — metal-to-metal, no rubber |
| Stabilizer Mount | Straight-bored with reversible stainless steel taper sleeve — supports drag link flip without losing stabilizer mount |
| Minimum Engagement Mark | Laser-etched — must remain hidden after adjustment; visible mark indicates unsafe thread engagement |
| Bearings | Rugged metal-to-metal |
| Boots | CR rubber accordion boots |
| Hardware | Grade 8 / Class 10.9 — castle nut at high-vibration load points |
| Lubrication | Pre-threaded Zerk housing, greaseable, pre-greased, gull-winged grease grooves |
| Finish | Black anodized aluminum |
| Lift Range | 2–6" |
| Weight | 21 lbs |
| Engine Compatibility | Gas & 6.7L Cummins diesel |
| BDS Trackbar | Not compatible |
| Rough Country Dual Stabilizer | Not compatible — component interference with drag link rod ends |
| Carli High Mount Stabilizer | Must use 2019+ Carli high mount regardless of truck year (applies to 2014–2018 trucks) |
| Ram 3500 DRW | Not compatible — SRW only |
| Alignment Required | Yes — full front-end alignment mandatory post-install |
| Install Difficulty | Intermediate — professional alignment required |
| Warranty | Apex Chassis manufacturer limited warranty — registration required |
| Country of Origin | United States |
| Sold As | Each — drag link only |
What Is and Is NOT Included
| Item | Included |
|---|---|
| 2" black anodized 7075-T6 aluminum drag link assembly | ✓ |
| ProLock washers and proprietary jam nuts with set screws | ✓ |
| Reversible stainless steel taper sleeve | ✓ |
| Grade 8 / Class 10.9 hardware | ✓ |
| Installation sheet with torque specs | ✓ |
| Tie rod | ✗ NOT included — sold separately as KIT386-BLK |
| Steering stabilizer | ✗ NOT included |
| Track bar relocation bracket | ✗ NOT included — recommended for lifts exceeding 4" |
| Dropped pitman arm | ✗ NOT included — may be required for lifts exceeding 4" |
KIT387 Finish/Material Options
| SKU | Adjusting Rod | Finish | Best For |
|---|---|---|---|
| KIT387-BLK (this listing) | 2" 7075-T6 aluminum | Black anodized | Zero-maintenance working trucks, road salt environments |
| KIT387-POL | 2" 7075-T6 aluminum | Raw mirror polished | Show-quality builds — restores with aluminum polish |
| KIT387-STL | 1.75" DOM SAE 1020 steel | Matte black powdercoat | Maximum rigidity, zero flex/memory under extreme impact |
Drag Link Only vs. Complete Master Kit
| SKU | Contents | Best For |
|---|---|---|
| KIT387-BLK (this listing) | Drag link only | Tie rod already upgraded or confirmed in good condition |
| KIT386-BLK | Tie rod only | Drag link already upgraded or confirmed in good condition |
| KIT385-BLK | Drag link + tie rod bundled | Both components need replacement — one install, one alignment |
Verified Fitment
| Vehicle | Years | Config | Status |
|---|---|---|---|
| Ram 2500 4WD — gas & 6.7L Cummins | 2014–2026 | SRW | ✓ |
| Ram 3500 4WD — gas & 6.7L Cummins | 2013–2026 | SRW | ✓ |
| Ram 2500 4WD | 2013 | Any | ✗ Retained legacy trailing-arm geometry — does not fit |
| Ram 3500 4WD | 2012 and earlier | Any | ✗ Different steering geometry |
| Ram 3500 DRW | Any | DRW | ✗ Axle widths and track lengths differ — contact us for correct SKU |
| Ram 2500/3500 | 2WD | Any | ✗ No solid front axle or drag link on 2WD |
| Ram 1500 | Any | Any | ✗ Different platform |
| Ford, GM, Toyota trucks | Any | Any | ✗ Not compatible |
Critical Compatibility
| Configuration | Notes |
|---|---|
| 2013 Ram 2500 | Does not fit — radius-arm suspension update came in 2014 on the 2500, one year after the 3500 |
| Ram 3500 DRW | Does not fit this SKU — text (469) 407-7538 to confirm correct SKU for a dually |
| BDS Adjustable Trackbar | Not compatible — confirmed by Apex Chassis and authorized distributors |
| Rough Country Dual Stabilizer | Not compatible — component interference with drag link rod ends |
| Carli High Mount or Dual Opposing Stabilizer | Must use 2019+ Carli high mount regardless of truck year — applies to 2014–2018 trucks |
| Minimum engagement mark visible after adjustment | Indicates unsafe thread engagement — may require a flip kit or sleeve redistribution between ends |
| Lifts exceeding 4" | Track bar relocation bracket strongly recommended; verify pitman arm drop compatibility |
Common Questions
What's the difference between KIT387-BLK and KIT387-POL?
Finish only. Same 2" 7075-T6 aluminum rod, same ProLock system, same Flopper Stoppers, same reversible taper sleeve, same 21 lbs. BLK is black anodized — zero maintenance, resists chips, heat cycles, and road salt. POL is raw mirror polished — show-quality finish that restores with aluminum polish over time.
Will this fix death wobble on my Ram 2500 or 3500 Cummins?
It eliminates the flex, joint slop, and adjusting sleeve rotation that heavily contribute to death wobble. The 2" 7075-T6 rod, ProLock system, and internal Flopper Stoppers remove the slop that allows wobble to develop. When paired with healthy ball joints, a solid track bar, and a proper alignment, it completely tightens up the front track.
Can I flip this drag link on a high-clearance lift setup?
Yes. The straight-bored stabilizer hole and included reversible stainless steel taper sleeve allow you to flip the link geometry at the pitman arm without losing the stabilizer mounting point. No fabrication required.
What does the minimum engagement mark mean?
A laser-etched safety reference line on the drag link threads. After adjusting the sleeve, this mark must remain hidden inside the sleeve. If it's visible, thread engagement is unsafe — redistribute the sleeve between the two ends, or the truck may need a flip kit.
I have a Carli high mount stabilizer on a 2016 Ram — what do I need?
Use the 2019+ Carli high mount regardless of your truck's model year. This applies to all 2014–2018 trucks.
The Obsidian Take
The KIT387-BLK is for the Ram HD owner who runs the truck hard and needs the steering to keep up without a maintenance schedule. Black anodized finish handles chips, heat cycles, and road salt without attention. The 2" 7075-T6 construction, Flopper Stoppers, Grade 8/Class 10.9 hardware, and ProLock adjustment retention are engineered for a Cummins diesel Ram 3500 pulling a gooseneck at GVW as much as a weekend trail truck.
If mirror finish matters more than zero maintenance, the mechanically identical KIT387-POL is the call. If maximum rigidity under extreme impact with zero flex memory is the priority, the KIT387-STL steel variant is the call. If your tie rod is also OEM, order KIT385-BLK and correct both in one session.
Confirm before ordering: 2013 Ram 2500 does not fit, Ram 3500 DRW requires a different SKU, and BDS trackbar and Rough Country dual stabilizer are hard incompatibilities.
Non-Returnable Notice: Steering components that have been installed are non-returnable. Confirm model year, SRW vs. DRW, trackbar and stabilizer configuration before ordering.
Manufacturer Data Disclaimer: Specifications sourced from Apex Chassis's own product page and authorized distributor documentation. Input data incorrectly stated adjusting rod diameter as 1.75" and finish as "black powdercoat" — confirmed correct diameter is 2" and -BLK designates black anodized aluminum per Apex Chassis's own finish designation system. Obsidian Forged Auto Supply is an authorized Apex Chassis dealer. Product registration required for warranty coverage. Manufacturer specifications are subject to change without notice.
