BDS 4-Inch Radius Arm Lift Kit | FOX 2.5 Performance Elite | Ram 2500 4WD Gas 2014–2018 | SKU: 1763FPE

Is This for You?

This kit is for the 2014–2018 Ram 2500 4WD gas owner who wants 4 inches of front lift with premium FOX 2.5 PE damping. This is the DS-generation Ram 2500 gas platform. If you have a 2019 or newer Ram 2500, stop here — that is the DT platform, order SKU 1699FPE. If your Ram 2500 is diesel, stop here — order SKU 1762FPE instead. Gas-tuned and diesel-tuned coil springs are not interchangeable.

The Result

4 inches of front lift with corrected caster, reduced bushing bind, and FOX 2.5 Performance Elite damping on the DS-generation Ram 2500 gas platform. The truck clears larger tires, sits level, and maintains consistent geometry under towing and hauling loads. The FOX 2.5 PE external reservoir shocks deliver heat-managed, consistent damping across sustained use.

Verified Fitment (OFAS Standard)

• Ram 2500 4WD Gas: 2014–2018

Does NOT fit: Ram 2500 diesel — order SKU 1762FPE for 2014–2018 Ram 2500 4WD diesel. Does not fit Ram 2500 2019 or newer — different platform, order SKU 1699FPE. Does not fit Ram 2500 2013 or earlier. Does not fit Ram 2500 2WD. Does not fit Ram 3500 or Ram 1500.

System Specifications

• SKU: 1763FPE
• Brand: BDS Suspension
• Lift Height: 4 inches (front)
• Suspension Type: Radius arm upgrade — heavy-duty BDS arms
• Shocks: FOX 2.5 Performance Elite — external reservoir, gas-tuned
• Application: Ram 2500 4WD Gas 2014–2018
• Warranty: BDS No-Fine-Print Warranty + FOX 1-year limited warranty

Master Kit Components

• Heavy-duty BDS radius arms — pair
• Gas-tuned front coil springs
• FOX 2.5 Performance Elite shocks with external reservoirs
• Track bar correction bracket
• All required installation hardware

Installation & Fabrication Notes

• Professional installation required: Radius arm lift requires a qualified suspension shop.
• Alignment mandatory: Full front-end alignment required after installation. Do not drive on public roads before alignment is completed.
• External reservoir routing: Follow BDS and FOX instructions for reservoir placement — avoid pinch points and heat sources.
• Torque specs: Torque all fasteners to BDS specification per included installation instructions. Do not estimate.
• Break-in period: Allow FOX 2.5 PE shocks to break in per FOX recommendations before aggressive off-road use.

Wheel & Tire Fitment

At 4-inch front lift on the Ram 2500 gas platform, typical fitment runs 35–37-inch tires depending on wheel offset and backspacing. Confirm maximum tire diameter and wheel specs with your wheel/tire supplier before ordering.

Installation Warning

Application-specific. Confirm 2014–2018 Ram 2500 4WD gas before ordering. Does NOT fit diesel — order SKU 1762FPE. Does not fit 2019+ Ram 2500 — order SKU 1699FPE. Does not fit 2WD or Ram 3500. This product is non-returnable once installed.

Is your Ram 2500 a 2014–2018 DS-generation or 2019+ DT-generation? Gas or diesel? Those two details determine which kit ships. Submit your year, engine, and drivetrain via the contact form and we’ll confirm the correct SKU before it ships.
