BDS 3.5-Inch Lift Kit | FOX 2.0 Coil-Overs | Cast Aluminum Knuckle | Ford Ranger 4WD 2019-2023

BDS 3.5-Inch Lift Kit | FOX 2.0 Coil-Overs | Cast Aluminum Knuckle | Ford Ranger 4WD 2019–2023 | SKU: 1545FSL

The BDS 3.5-Inch Lift Kit is a complete front lift system for 2019–2023 Ford Ranger 4WD models equipped with cast aluminum front knuckles, featuring FOX 2.0 Performance Series coil-overs. The FOX 2.0 coil-over replaces both the factory strut and coil spring as a single integrated unit, delivering improved damping control and ride quality at 3.5-inch lift height. Cast aluminum knuckles maintain proper geometry at lifted height. This kit is for cast aluminum knuckle models only — if your Ranger has cast steel knuckles, order SKU 1906FSL instead.

Verified Fitment (OFAS Standard)

• Ford Ranger 4WD: 2019–2023 — cast aluminum knuckle models only

Does NOT fit: Ford Ranger with cast steel knuckles — order SKU 1906FSL. Does not fit Ford Ranger RWD/2WD. Does not fit 2024+ Ranger — different platform. Does not fit 2018 or earlier Ranger — no US-market Ranger sold 2012–2018. Does not fit F-150 or F-250.

Technical Specifications

• SKU: 1545FSL
• Brand: BDS Suspension
• Lift Height: 3.5 inches (front)
• Front System: FOX 2.0 Performance Series coil-overs with cast aluminum knuckles
• Application: Ford Ranger 4WD 2019–2023 — cast aluminum knuckle models
• Warranty: BDS No-Fine-Print Warranty + FOX 1-year limited warranty

Cast Aluminum vs. Cast Steel Knuckle — Which Kit Do You Need?

The 2019–2023 Ford Ranger 4WD was produced with two different front knuckle materials. BDS engineers separate kits for each. Confirm your knuckle type before ordering — ordering the wrong kit results in fitment incompatibility.

• Cast aluminum knuckle — this listing (SKU 1545FSL): 3.5-inch lift, FOX 2.0 coil-overs, cast aluminum knuckles included
• Cast steel knuckle — order SKU 1906FSL: 3.5-inch lift, FOX 2.0 coil-overs, cast steel knuckles included

Kit Contents

• FOX 2.0 Performance Series coil-overs — pair (front)
• Cast aluminum knuckles
• BDS geometry-correct lift components
• All required installation hardware

Installation Notes

• Professional installation required: Coil-over and knuckle installation requires a qualified suspension shop.
• Alignment mandatory: Full front-end alignment required after installation. Do not drive on public roads before alignment is completed.
• Knuckle type confirmation: Confirm cast aluminum knuckle configuration before installation. Incorrect knuckle kit voids fitment.
• Torque specs: Torque all fasteners to BDS specification per included installation instructions.
• Break-in period: Allow FOX coil-overs to break in per FOX recommendations before aggressive off-road use.

Installation Warning

Application-specific. Confirm 2019–2023 Ford Ranger 4WD with cast aluminum knuckles before ordering. Does NOT fit cast steel knuckle models — order SKU 1906FSL. Does not fit RWD/2WD. Does not fit 2024+ or 2018 and earlier Ranger. This product is non-returnable once installed.

Engineering Question? Submit your Year / Make / Model / knuckle type / current lift height via the contact form and an OFAS fitment specialist will respond with a verified recommendation.
